VR mod sources and acknowledgements

This community VR mod installer builds the experimental native ARM64 Linux VR port of Halo: Combat Evolved from the revision below. It provides a guided installation; the decompilation, renderer, OpenXR implementation and networking are the work of the credited upstream contributors. No retail game executable, disc image, maps, product keys, or soundtrack is bundled or downloaded; users provide authorized original Xbox game data.

Sources were checked on 2026-10-05. Links to pinned files describe the build used here; moving documentation may describe newer behavior.

Installer contributions

dime-online contributed the fixes for interrupted uninstalls (#7), renamed native Steam shortcuts (#8), and SSH cancellation/error handling (#9), addressing issues #1, #2, and #3. Release 1.3.5 builds on those contributions with operation-record and directory-identity checks before resuming file removal, explicit pending-removal and cleanup results, refusal of malformed native shortcut IDs before writes, and one bounded cancellation recovery connection using the already-approved host key.

These changes affect installer recovery and library cleanup. The pinned native game source, controller/tutorial patch, and game-data requirements are unchanged. Automated regression coverage does not replace physical Frame verification of interruption, cancellation, and full uninstall.

Native game and VR

Source	Contribution or verified requirement
startupfoundry's native Steam Frame VR work, OpenCE PR #85	OpenXR stereo, tracked head and controllers, native ARM64 host, desktop OpenGL and stereo multiview. This is experimental work in an open pull request. The normal upstream CI builds do not enable --vr.
Pinned fork revision 88142798513ebd99fc7c6224023e8b44c05d0106	Exact source revision selected for this installer, rather than a moving branch.
Upstream build instructions	Native ARM64 compiler requirements, SDL 3.4.16, musl 1.2.5, and the linux_arm64 target.
Upstream VR documentation	configure.py --vr, OpenXR runtime requirements, motion aiming, gamepad mode, comfort options, and experimental limitations.
OpenCommunityEdition/OpenCE	Community port and integration work from which the VR fork descends.
bnunu/halo-1 and punpckhdq/halo	Decompilation lineage identified by the upstream README.
Upstream XDK declarations	The port supplies its own declarations; installing the proprietary Xbox SDK is unnecessary.

The installer applies its documented controller and tutorial patch to that pinned revision. Controls and defaults distinguish these changes from upstream behavior. Performance depends on game scene, headset software and settings; native ARM64 does not imply unlimited performance.

Game data and compatibility

Upstream game-data instructions require an original Xbox Halo: Combat Evolved disc image (.iso or .xiso) or its extracted maps. This installer uses the exact released-map build list in the pinned cache compatibility table:

Accepted Xbox version-5 map build	Upstream region
01.10.12.2276	NTSC
01.08.15.1749	NTSC
01.01.14.2342	PAL

USA Rev 2 is validated with this installer. Other original Xbox retail revisions and regions, including an image labeled USA Rev 1 or the original USA release, are accepted only when all 24 required maps have one of these builds. Upstream PAL conversion notes identify shared NTSC maps across three releases and explain the PAL timing conversion. Those source files do not provide a definitive filename-to-Rev-label mapping; setup validates actual headers instead of trusting a filename. Incomplete or mixed-build sets and other build strings are rejected. This is a supported-data rule, not a claim that every disc pressing has been tested on a Frame.

Select a local disc image or maps that you are authorized to use. The installer checks original Xbox map headers and extracts the required data locally. The repository and downloadable installer contain no game disc image or commercial map data and provide no unauthorized game-download links.

Halo PC, Custom Edition, Xbox 360 Anniversary and MCC data are different formats. This is the native Steam Frame Linux VR port; the Android port in the upstream repository is not a promise of a Quest VR installation. PC Chimera, PC Restored map replacements and HaloCEVR DLLs are not loaded by this ARM64 build. Its native renderer and VR implementation supply the relevant graphics and headset support. PC Halo saves and profiles also differ from the native port's Xbox formats.

Upstream multiplayer supports LAN and internet play among compatible builds of this port. The netcode design describes its replacement networking. Use matching native/OpenCE protocol versions; compatibility with legacy Halo PC, Custom Edition, MCC or retail Xbox servers is not established by this project.

Steam Frame setup and connection

Primary reference	Installer guidance
Valve: Setting up your Steam Frame for development	In the headset, open Steam Settings > System > Enable Developer Mode. Open Developer > Set User Password and choose a password. The hostname is under Steam Settings > System > Hostname.
Valve: Steam Frame Debugging	Developer Mode enables SSH and ADB. Valve's default SSH login is ssh steamos@frame, using the password you set; its USB instructions connect the headset directly to the PC with a cable and use ADB.
Google: Android Debug Bridge	Documents ADB device selection, authorization, and host-to-device TCP port forwarding. Setup forwards a temporary PC port to the Frame's SSH port so encrypted SSH/SFTP can use the physical USB connection.
AOSP: ADB manual	Defines physical-device selection, serial selection, device paths, dynamic TCP forwarding, and removal of an individual forward.
Google: SDK Platform Tools download and terms	Official Windows ADB distribution, download terms, and release notes. Setup bundles the verified ADB components with their original notices; the page is also the advanced replacement-download reference.
OpenSSH manuals and Paramiko host-key policies	SSH host keys identify the destination device. Review the first-connection fingerprint; an unexpected changed key should stop the connection.

SteamOS has a read-only system filesystem. This installer uses a user-owned game folder and an unprivileged build container; its process does not require disabling that protection or changing system packages.

USB transfer behavior and verification limits

Version 1.3.0 adds USB-C cable alongside Network (Wi-Fi or Ethernet). USB selects the sole physical device or requires an exact serial when several are attached; emulators and ADB network devices are excluded. SSH retains its password and SHA256 host-key approval, independent of ADB authorization. Setup removes only its own temporary forward after closing SSH, including failure and cancellation, and leaves the shared ADB server and other forwards alone. It does not change the Frame's Wi-Fi or Steam settings.

The bundled components are ADB 37.0.1 (protocol 1.0.41) from the pinned Google Windows archive, whose SHA256 is 45f4d63113e895ebde0c90f194099a4676b6ac653bd28d54314a9e022bbc1a99. resources/usb/manifest.json records selected-file checksums and THIRD_PARTY.md links the retained notices, AOSP source-license references, and Google's section 3.5 open-source component terms. The build helper fetches and verifies the archive when creating the EXE; setup does not download SDK tools during an installation.

Runtime prefers an existing ADB client on PATH, then its bundled files; an explicit advanced selection overrides discovery. Bundled files and notices are verified and cached in a persistent, versioned per-user folder. Setup checks server/client protocol compatibility before normal commands, clears inherited remote-server overrides, and verifies actual OS loopback bindings for its forward before sending the SSH password. Unsupported or unverifiable results stop USB setup and show corrective steps rather than resetting shared services.

The cable carries PC-to-Frame transfer and commands. The Frame still needs internet for source, containers, and compiler dependencies, and the native compilation runs on the Frame as before. Neither cited reference establishes an installer speed benchmark or guarantees faster transfers. USB selection, forwarding, authentication integration, and cleanup have software tests; a physical Steam Frame USB transfer has not yet been verified. The previously tested native game and live Steam-library behavior do not establish USB hardware compatibility on every SteamOS release.

Steam session safeguard

Valve's Frame debugging documentation documents the standalone SteamOS environment, developer SSH access, remote headset view, and Steam log location. It does not provide a current Frame-specific command to stop and recreate the headset's Steam session from SSH.

During investigation of a reported loading-logo failure after a 1.2.2 run, the tested Frame's installed SteamOS user service was configured to restart Steam automatically. Device diagnostics showed that service in a failed start-limit state after repeated supervised restarts while the VR service remained active. The installer had timed out waiting for its requested Steam shutdown, leaving the library files unchanged; its separate client-launch path was not reached. These are observations from the installed service and that device, not a claim that every Frame loading-logo problem has the same cause. No private logs or credentials are included here.

Version 1.2.3 removes automatic Steam shutdown and separate client launches. It keeps Steam Home and SteamVR running, guards against directly editing a running client's library/artwork files, and reports manual steps when required. The saved-and-closed-games checkbox permits game-file work; it is not permission to restart Steam. Automatic file registration and removal operate only when Steam is already closed. This safeguard prevents the installer from issuing the problematic shutdown request; recovering a previously failed headset session is a separate action.

The live library helper uses the currently installed client's SteamClient.Apps interface through its existing local CEF context. These are observed, undocumented client interfaces rather than a stable public Steamworks API. The helper checks endpoint ownership, capabilities, exact native executable identity, and readback within bounded requests. Artwork uses the client's SetCustomArtworkForApp method, with the active account matched to one owned local profile, existing custom images preserved, and the resulting files verified against the bundled source hashes. It does not enable a new remote debugger, change the session launch command, or write the live shortcut VDF or grid files directly. Unsupported or unverified results produce manual Add/Remove/artwork steps. Live removal affects the active client account and leaves artwork files under Steam's control; already-closed removal can handle local account files and removes only known installer artwork hashes. Future Steam builds may need an updated adapter.

The final 1.2.3 helper was tested on one Frame for native shortcut removal and re-addition, exact executable/launch/VR/compatibility settings, and fresh creation of cover and landscape artwork with exact source-hash readback. A prior check preserved and verified both existing managed image hashes. Steam and VR services remained active and unchanged, and the game binary was unchanged. The user confirmed Steam Home worked after separate recovery through the device's installed managed launcher, and later confirmed the native entry and artwork looked correct. These checks do not establish a complete fresh installation, game uninstall, USB transfer, or listening test.

Build and installer dependencies

• LLVM's signed Ubuntu package repository supplies LLVM 22 inside the build container for the upstream arm64_32 guest compiler target.
• Ninja's environment-variable documentation defines the finished and total build-task counts used for measured compilation progress. The installer's overall percentage combines phase weights, transferred bytes, and completed build tasks; it is not a time or performance estimate.
• Podman's rootless operation isolates compiler dependencies from the headset's system installation.
• Podman run: container user and user namespaces documents how --user selects the container UID/GID and how --userns=keep-id otherwise starts the process as the caller's UID. Setup explicitly uses --user=0:0 for container dependency installation while Podman remains rootless under the ordinary host user. Its security options define the retained no-new-privileges restriction.
• SDL provides native windowing, audio and gamepad support. Its Steam virtual-gamepad hint supports suppressing duplicate virtual-pad input for this game's shortcut.
• Khronos OpenXR supplies the OpenXR API headers used by the upstream VR implementation. The Frame's installed runtime supplies the active headset session.
• Paramiko provides SSH/SFTP for the Windows installer, using cryptography, bcrypt and PyNaCl.
• CPython and Tcl/Tk provide the installer runtime and guided desktop interface. PyInstaller creates the Windows executable.

Actual package versions, original license notices and source references are recorded in third-party notices and the generated license manifest. The installer code's license does not replace the upstream or dependency licenses.

This product includes software developed by in in@fishtank.com (the upstream extract-xiso component).

Dashboard visual references

• Martin Nobel's original Xbox dashboard screenshots document the console's main menu, settings, and other screens. They serve as visual references for the installer's dark panels, green accents, and beveled interface.
• Microsoft's November 5, 2001 Xbox launch campaign announcement describes the original console's glowing green jewel campaign and identifies Halo among its launch titles.

These links credit visual and historical references. Dashboard styling is an independent installer interface; the project is unaffiliated with Microsoft or Xbox. Original screenshots, game artwork, and trademarks retain their respective owners' rights.

Steam library artwork

The Windows installer uses the classic Halo PC helmet-and-shoulders icon in 1.3.2. HaloNet's favicon ICO is byte-identical to icon group 102 of the locally installed retail Halo PC executable. Only the icon is bundled; its resource notice records the verification and exact hashes. The README displays only the banner and title logo, with the installer icon separate from Steam's retained project drawing.

The bundled portrait image is the original Halo: Combat Evolved cover from Halopedia's cover-art file page, with the original JPEG. Halopedia records the official Halo Facebook image as its source. The landscape library image arranges the same cover in a wider layout without stretching it.

The cover remains copyrighted Microsoft/Halo artwork; the installer's MIT license does not apply to it. Source attribution and exact hashes are retained in the artwork resource notice and described in THIRD_PARTY.md. A thumbnail appears inside the installer. The library images are applied only to its native Halo shortcut, preserving user-selected custom art. The user confirmed the entry and covers looked correct on the Frame tested with 1.2.3.

Version 1.3.1 adds a 1,920 × 620 banner cropped from the original CE Scorpion/Chief promotional image. Halopedia's source record documents the official Xbox Imagery, 11 Jan 2002 press CD-ROM and original HI_06_HO.TIF filename. The transparent title image comes from Halopedia's Halo CE logo record; this record does not identify a publisher URL or grant a new license. The shortcut icon reuses the project's original helmet drawing. Valve's library-asset specifications describe the hero/banner and transparent logo roles and dimensions. Their specification is a visual-format reference, not documentation of the installer's private client adapter.

The new adapter's artwork type mapping, SetCustomArtworkForApp, SetShortcutIcon, and Game Notes schema were checked against the installed Steam client's own JavaScript on 5 October 2026. The steamui/library.js GameNotesCloudStore and its associated chunks use notes_shortcut_<sanitized name> documents containing a shortcut_name and an array of BBCode notes. These are observed, undocumented interfaces. Live icon changes also require read-only owned shortcut-file proof and a confirmed empty resident icon; uncertain or custom icons are kept. No live Steam file writes or session restarts are added.

Description and controls in Steam Notes

Valve's June 2023 Steam update, also available in its official announcement feed, introduces rich-text Notes accessible from a game's details page and overlay, with Steam synchronization. This patch uses Notes for an original Halo summary, Xbox controls, compatibility guidance, and source links. It does not replace Steam's non-Steam About text or create official store metadata.

The helper matches the current account and exact native executable before writing, synchronizes before reading, preserves the full existing document, guards against intervening changes, saves one identified note, and verifies the result. User-edited installer notes remain untouched. Unsupported schemas, account/name ambiguity, or synchronization failures produce a manual, copyable description. Notes use Steam's normal private-note synchronization; setup sends no description to another game's app ID or outside service. The banner, logo, icon, and Notes have automated tests but still need verification on a physical Frame.

Local Halo menu music

The preview reads only the sound\music\title1\loops sound tag from the user's selected original Xbox ui.map, either inside an ISO/XISO or in extracted maps. Cache and sound structures are based on the pinned native port's cache_files.c and sound_definitions.h. Xbox ADPCM decoding follows its dsound_sdl.c implementation.

The installer decodes the loop into a private temporary Windows WAV with a fixed 12% sample-amplitude gain. Playback loops automatically after local game data validates. Closing the installer stops playback and clears its temporary audio. No soundtrack is present in the repository or executable, fetched from a website, or uploaded over SSH. Audio-file extensions are rejected by the release packager. Remote-only repair has no local audio preview, and an unavailable preview does not block installation. The original music remains copyrighted game content; the installer's code license does not apply to it. Playback still needs a listening check.
